unity_open_mcp_list_rules

Enumerate validation rules, optionally filtered by asset kind or file extension, omitting planned rules when requested.

asset_kind

string

Filter to rules that declare this asset kind (e.g. prefab, scene, material).

extension

string

Filter by file extension (e.g. .prefab). Case-insensitive.

unity_open_mcp_manage_tools

Activate or deactivate a tool group for this session (list_groups / activate / deactivate / reset). State is ephemeral and in-memory; resets to core-only on restart.

action

string

list_groups | activate | deactivate | reset.

group

string

Group id (required for activate/deactivate).

{ "action": "activate", "group": "navigation" }

unity_open_mcp_generate_skill

Generate a SKILL.md playbook for the connected client (cursor/claude/opencode/agents), previewing or writing it to disk.

unity_open_mcp_read_compile_errors

Read the tail of the Unity Editor.log to surface compiler errors and assembly-resolution failures as structured diagnostics.

unity_open_mcp_pull_events

Drain buffered console and editor-state events (SSE/poll feed) for live UIs and validation suites.

max_events

integer

Max events to return per call (1–1000).

unity_open_mcp_execute_csharp

Run an arbitrary C# snippet in the editor with injected Refs[] and return the serialized result graph.

code

string

C# source. Use return x; to produce output.

unity_open_mcp_invoke_method

Invoke a static or instance method by type and name, with JSON arguments and optional generic type parameters.

type_name

string

Fully qualified type name.

method_name

string

Method name.

unity_open_mcp_find_members

Search loaded assemblies for types/members/properties/methods by substring, with optional signature metadata.

query

string

Substring filter on type or member name.

kind

string

type | method | property | all.

unity_open_mcp_compile_check

Wait for compilation to settle and report whether it succeeded. Route-pinned to batch mode.

timeout_ms

integer

Max wait for compilation to settle.

unity_open_mcp_validate_edit

Run verify rules against the given asset paths (auto-selecting categories) and return issues with severities.

paths

string[]

Asset paths to validate.

detail

string

summary | normal | verbose.

unity_open_mcp_checkpoint_create

Snapshot a scope of paths (or whole project) for a later delta comparison.

paths

string[]

Scope; empty = whole-project summary.

label

string

Optional label.

unity_open_mcp_delta

Re-validate the scope of a checkpoint and report what changed since it was created.

checkpoint_id

string

Checkpoint id from checkpoint_create.

unity_open_mcp_find_references

Find assets referencing a target by asset path or GUID, grouped by kind/folder, with verbose field locations.

asset_path

string

Asset path (or use guid).

unity_open_mcp_scan_paths

Scan specific asset paths with selected verify rules; auto-selects categories from paths when omitted.

paths

string[]

Asset paths to scan.

unity_open_mcp_apply_fix

Apply (or dry-run) a fix action for an issue id — e.g. remove_missing_script or relink_broken_guid.

issue_id

string

Issue key from validate_edit or scan_paths.

dry_run

boolean

Preview without applying. Default true.

unity_open_mcp_scan_all

Run every verify rule across the whole project and return a JSON report (optionally written to disk).

fail_on_severity

string

error | warn | info | verbose | never.

unity_open_mcp_regression_check

Compare current scan results against a saved baseline and fail when issue counts exceed thresholds.

baseline_path

string

Path to a baseline JSON file.

unity_open_mcp_read_asset

Read a text-serialized YAML asset as a folded tree, with summary/normal/verbose detail and component/path drill-downs.

asset_path

string

Asset path (.prefab/.unity/.asset/.mat/.controller/.anim).

unity_open_mcp_search_assets

Search YAML assets by name, component, type, or GUID across a folder, returning matched files with optional per-file object listings.

name

string

Substring filter on file or GameObject name.

component

string

Substring filter on component/script name.

unity_open_mcp_list_assets

List assets under a folder, optionally filtered by asset kind, with per-folder sampling to control verbosity.

folder

string

Folder to list under (default Assets).

type

string

Comma-separated asset kinds (e.g. prefab,scene).

unity_open_mcp_material_set_property

Set a shader property (color/float/int/vector/texture) on a material asset or a renderer's shared material.

property

string

Shader property name.

type

string

color | float | int | vector | texture.

value

any

New value; shape depends on type.

unity_open_mcp_prefab_open

Open a prefab asset in the edit stage for isolated editing.

prefab_asset_path

string

Prefab asset path to open.

unity_open_mcp_gameobject_create

Create a GameObject (optionally a primitive) at a path with transform and parent options.

name

string

Name for the new GameObject.

primitive_type

string

Cube/Sphere/Capsule/Cylinder/Plane/Quad, or omit for empty.

unity_open_mcp_component_modify

Patch serialized fields on a component (resolved by host path/name/instance_id), including object references and enum-by-name.

type_name

string

Component type to modify.

fields

array

Serialized-property patches [{ path, value }].

unity_open_mcp_scene_open

Open a scene single or additive, with a scene-dirty guard to avoid losing unsaved changes.

path

string

Asset path of the scene (.unity).

mode

string

single | additive.

unity_open_mcp_package_add

Add a UPM package by id, version, Git URL, or local path/tarball; gate-validates against Packages/manifest.json.

package_id

string

Package specifier (id, id@ver, git URL, file: path).

unity_open_mcp_script_write

Write a .cs file with Roslyn pre-write validation; parse errors return validation_failed and the file is not written.

file_path

string

Project-relative .cs path.

content

string

Full C# source.

unity_open_mcp_profiler_start

Start the Unity Profiler and optionally open the Profiler window for live capture.

open_window

boolean

Also open the Profiler window. Default true.

unity_open_mcp_build_start

Start a player build. BuildPipeline.BuildPlayer is on the default deny list, so this requires gate: off + confirm_bypass.

scenes

string[]

Scene paths to include.

location_path_name

string

Output path.

unity_open_mcp_settings_set_player

Mutate Player settings; uses the restart_then_settle gate strategy because it may domain-reload.

fields

array

Player-settings field patches.

unity_open_mcp_selection_set

Set the editor selection from scene objects or disk assets, or clear it entirely.

targets

array

Multi-selection list of { instance_id | asset_path | path | name }.

group: input-system

Gated on com.unity.inputsystem. Build InputActionAssets, action maps, actions, bindings, composites, and control schemes.

tools

string

inputsystem_asset_create, inputsystem_action_add, inputsystem_binding_composite_add, … (7 tools).

group: probuilder

Gated on com.unity.probuilder. Create shapes, inspect mesh info, extrude, set face materials; probuilder_delete_faces is the lone destructive tool.

tools

string

probuilder_create_shape, probuilder_extrude, probuilder_set_face_material, … (5 tools).

group: particle-system

Gated on UnityEngine.ParticleSystemModule. Read and modify particle system modules.

tools

string

particle_system_get, particle_system_modify (2 tools).

group: animation

Gated on com.unity.modules.animation. Create and edit AnimationClips and AnimatorControllers, including keyframes, layers, states, and transitions.

tools

string

animation_create/modify, animator_create/modify, … (6 tools).

group: splines

Gated on com.unity.splines. Create spline containers, add/modify knots, set tangent modes, and evaluate splines.

tools

string

splines_container_create, splines_add_knot, splines_evaluate, … (7 tools).

GET /tools

Compiled-state tool inventory + group→tools map

Lists the bridge tools compiled into the current editor state, including which domain packs compiled in, and maps tool groups to their tools.

POST /tools/{toolName}

Execute one bridge tool

Runs a single bridge tool with a JSON envelope; returns ok/result/error plus optional lifecycle/settle metadata for mutating tools.

GET /events

SSE event stream

Server-Sent Events stream of console and editor-state events; /events/poll provides a pull-style drain for environments without SSE.

GET /resources, GET /resources/{route}

List and read bridge resources

Enumerate and read bridge-side resource payloads.

unity-open-mcp://health/summary

MCP resource: cached verify health summary from the last scan or gate validation.

unity-open-mcp://tool-groups

MCP resource: static tool-group catalog (ids, descriptions, default-enabled flags).
